Image Device

Sony Exmor™ Starvis level,
2.41 Mega-pixel image sensor, 1/2.8“ size

Effective Pixels

1920x1080 pixels

Lens

2.8-12mm remote motorized zoom Lens

Focus

Auto Focus

ICR type

Mechanical

IR LED

24pcs IR LED 40meter IR distance

Video

Video Encoder

H.264 and MJPEG simultaneously

Video Profile

Dual stream for WDR mode (Resolution Adjustable)

Wide Dynamic Range

More than 120dB (double scan sensor)

Frame Rate

Up to 60fps for 60fps mode
Up to 30fps for WDR mode

Exposure Control

Auto / Auto Indoor / Manual Exposure
(Manual mode : 1/2~1/10,000 seconds)
Photometry Method : Average / Center / Spot / BLC / FLC

Image Setting

AE, AWB
3D Noise reduction
Ture WDR
Exposure value, Color, Hue , Brightness, Contrast, Sharpness,
Mirror/Flip
DIS
Privacy masks
Pixel count

On Screen Display

Text, time and date overlay
Editable OSD (bitmap format)

Area of Interest

Higher quality in AOI area

Streaming

Simultaneously dual streaming
Streaming over UDP, TCP, HTTP, or HTTPS
M-JPEG streaming over HTTP (server push)
Controllable frame rate and bandwidth
Constant and variable bit rate (H.264)

Audio

Audio Encoder

RTSP: G.711 64kbps, G.726 32kbps, AAC (option, by request)

Audio Streaming

One-way or two-way

Microphone

External microphone

Audio Output

Adjustable audio output gain

Network

Supported Protocols

IPv6, IPv4, TCP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, DDNS, DHCP, DIPS, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP, PPPoE, 3GPP, Samba, ICMP, SNMP , QoS

Security

Password protection, IP address filtering, HTTPS encrypted data transmission, user access log

Users

20 simultaneous unicast users

Ethernet

10/100/1000M auto negotiation

System Integration

SDK

ONVIF
Open API for software integration

Event Detection

IVA trigger : Object Detection (Missing object), Camera tampering, Face Detection, Cross Line Detection (tripwire)

Object Detection

Detection with Entrance , Desertion or Theft options

Audio Detection

Audio level 0-100

Camera Tampering

Camera dis-focus / move direction / mask

Cross Line

User defined two cross line , and user defined entrance direction

Alarm Events

Push notify to smart phone apps
File upload via FTP or email
File upload via Samba to NAS
Notification via email, HTTP, and TCP

Video Buffer

Pre- and post- alarm buffering

General

RAM

384MB

ROM

256MB

Power Supply

12V DC external power adapter

PoE

IEEE 802.3af class 3

Power Consumption

Max. 10W (12V DC in)

Connectors

RJ-45
12VDC power jack

Indication LED

Green and orange LEDs

Operating Temperature

-10°C to 50°C

Operating Humidity

20% ~ 80% (non-condensing)

Construction

IP66 weather proof
IK10vandal proof

Dimension

258.3 x Φ80 mm

Viewing System

OS

Windows XP, Vista, 7, 8 , 8.1

Browser

IE 7.0 or later, Firefox 2.0 or later, Safari , Google Chrome

Software

Search & Installation

IP Wizard II

Easy DDNS

DIPS

Bundled NVR Program

64ch. SecuGuard™
* 64ch. multi-channel supports Tri-decoder
* 16ch. video playback (simultaneously)
* Smart & scrollable digital zoom. Snapshot and edit
* Motion, DI, Scheduler recording
* Fast rewind and forward (MPEG4, H.264, MJPEG rewind)
* 32x24 motion detection grids
* Smart search (by time, by motion)
* E-MAP
* Event schedule setting
* Remote service
* Camera tampering

Bundle Mobile Phone APPS

SecuAngel (Android) and iVanguard (iOS)

本型錄中產品的配備及規格依實際出貨為準，配備及規格若有變更將不另行通知。
